Nominal Diameter |
0,75"- 20 mm |
Rated Impedance |
4 Ohm |
Nominal Power Handling 1 |
60 W |
Program Power 2 |
100 W |
Sensitivity 3 |
90 dB (1W/1m) |
Frequency Range 4 |
2000-20000 Hz |
Minimum Impendance |
- |
Basket Material |
Plastica |
Magnet Material |
Ferrite |
Cone Material |
Poliammide |
Cone Shape |
Cupola |
Surround |
- |
Suspension |
- |
Voice Coil Diameter |
0,78 in - 20 mm |
Voice Coil Winding Material |
- |
Voice Coil Length |
2 mm - 0,08 in |
Voice Coil Former Material |
Kapton |
Connection Type |
Faston |
Ferrofluid |
No |
Magnet Gap Height |
2 mm - 0,08 in |
Max. Peak to Peak Excursion Xlim |
- |
Efficiency Bandwidth Product EBP |
909 |
Recommended Loading |
- |
Volume/ Tuning Frequency |
|
Maximum Recommended Frequency |
- |
Version - Part Code |
|
